OPTEX Xwave2 FIT wireless outdoor compact PIR

OPTEX Xwave2 FIT Wireless Outdoor Compact PIR

Compact Outdoor Motion Detection

The OPTEX Xwave2 FIT Wireless Outdoor Compact PIR is a discreet outdoor motion detector designed to protect building entry points, windows, doors, balconies and other defined outdoor areas. Its compact design and narrow detection pattern make it ideal for applications where focused short-range protection is required.

Narrow 5 m × 1 m Detection

The FIT provides a narrow detection area of up to 5 metres by 1 metre, creating a focused detection curtain around the protected area. The detection range can also be adjusted to 2 metres, allowing the detector to be configured according to the installation requirements.

Wireless Xwave2 Integration

The OPTEX Xwave2 FIT is designed for wireless security installations and can be integrated with compatible Xwave2 systems. Its wireless configuration provides greater flexibility when protecting entry points and outdoor areas where traditional cabling may be difficult or impractical.

Dual-Element Pet PIR

The FIT uses a dual-element PIR detection system with intelligent detection logic. This helps provide reliable motion detection while offering tolerance to small animals and pets, making it suitable for residential outdoor applications.

Flexible 190° Mounting Adjustment

A built-in mounting bracket provides approximately 190° of horizontal adjustment. This allows the detection direction to be positioned precisely according to the building, boundary or entry point being protected.

SMDA Environmental Analysis

OPTEX’s SMDA logic helps analyse environmental conditions and distinguish relevant movement from potential outdoor disturbances. This supports reliable operation in changing outdoor environments.

Intelligent Detection Logic

The FIT uses intelligent AND detection logic, requiring the appropriate PIR elements to be activated before an alarm condition is generated. This helps improve detection reliability and reduce unnecessary activations.

Compact & Discreet Design

The compact housing makes the FIT particularly suitable for installations where a discreet security sensor is preferred. It can be used around doors, windows, balconies and other vulnerable entry points without requiring a large detector footprint.

Built for Outdoor Conditions

The OPTEX Xwave2 FIT features an IP55-rated housing and UV-resistant ASA construction for outdoor applications. It is designed to operate in temperatures from approximately -20°C to +60°C.

Suitable for Residential & Commercial Security

The FIT is suitable for protecting entry points and defined outdoor areas around homes, offices, commercial buildings and other properties requiring compact wireless motion detection.

Key Features

• OPTEX Xwave2 FIT wireless outdoor compact PIR
• Model 862-22-FTN-R
• 5 m × 1 m narrow detection area
• Selectable 2 m or 5 m detection range
• Dual-element pet PIR
• Intelligent AND detection logic
• SMDA environmental analysis
• Built-in 190° horizontal adjustment
• Compact and discreet design
• Wireless Xwave2 integration
• IP55 outdoor protection
• UV-resistant ASA housing
• Operating temperature of approximately -20°C to +60°C
• Suitable for doors, windows, balconies and entry points

Protect Vulnerable Entry Points

The OPTEX Xwave2 FIT Wireless Outdoor Compact PIR provides focused, discreet and flexible outdoor motion detection for compatible Xwave2 security systems, making it an effective solution for protecting defined entry points and perimeter areas.
