Ubiquiti UniFi Cloud Gateway Dream Router 7 | UDR7

The Ubiquiti UDR 7 UniFi Dream Router 7 is a cutting-edge networking solution designed for both home and business environments. This device features an integrated 6-stream WiFi 7 access point with support for the 6 GHz band, ensuring ultra-fast connectivity and minimal interference. With the ability to manage over 30 UniFi devicesand more than 300 clients, it is perfect for high-demand settings requiring robust network performance.

Equipped with an integrated 4-port switch that includes one PoE port, the UDR 7 simplifies your network setup while providing essential connectivity options. Additionally, it features one 10G SFP+ and one 2.5 GbE RJ45 WAN port, facilitating high-speed internet access and seamless data transfer. The device also comes with 64 GB microSD storage pre-installed, which is upgradable, allowing for extensive data management and storage capabilities.

Utilising the full UniFi application suite for device management, the Ubiquiti UDR 7 offers an intuitive interface for monitoring and controlling your network. This model stands out in its class due to its advanced technology and comprehensive features, making it a superior choice for those seeking reliable and efficient networking solutions.

Key Features

• 1 x 10G SFP+ & 2.5Gbps WAN port, 1 x PoE out port, 3 x 2.5Gbps ports

Dimensions

• Ø110 x 184.1 mm (Ø4.3 x 7.3″)

UniFi Application Suite

• Network✓
• Protect✓
• Access✓
• Talk✓
• Connect✓
• Managed UniFi Devices – 30+
• Managed Cameras – (5) HD (2) 2K (1) 4K
• Simultaneous Users Connected – 300+
• Default WAN Ports – (1) 10G SFP+ (1) 2.5 GbE RJ45
• LAN Ports – (3) 2.5 GbE RJ45 including (1) PoE
• IDS/IPS Throughput – 2.3 Gbps
• Form Factor – Compact desktop
• Coverage Area – 160 m² (1,750 ft²)

Security

• Stateful Firewall✓
• Application-Aware Layer 7 Firewall✓
• DPI & Traffic Identification✓
• Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)✓
• Content Filtering✓
• Intrusion Prevention (IPS/IDS)✓
• Ad Blocking✓
• IDS/IPS Signatures – 20,000+ with CyberSecure
• VLAN/Subnet-based Traffic Segmentation ✓

VPN & SD-WAN

• License-Free SD-WAN✓
• Site-to-Site VPN
• Site Magic✓
• IPsec✓
• OpenVPN✓
• VPN Server
• Identity Endpoint One-Click VPN✓
• Teleport Zero-Configuration VPN✓
• WireGuard✓
• OpenVPN✓
• L2TP✓
• VPN Client
• OpenVPN✓
• WireGuard✓

Networking

• Multi-WAN Load Balancin✓
• Dynamic Routing
• OSPF✓
• Advanced QoS✓
• Multicast DNS (mDNS)✓
• Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT)✓
• Integrated RADIUS Server✓
• RADIUS over TLS (RadSec)✓
• Additional Internet Failover with UniFi LTE Backup✓
• Internet Quality and Outage Reporting✓
• MAC Address Table Size – 2,000
• Policy-based WAN and VPN Routing✓
• Customizable DHCP Server✓
• IPv6 ISP Support✓
• IGMP Proxy✓

Integrated WiFi

WiFi Standard

• 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7)

Throughput

• 6 GHz
• 5.7 Gbps
• 5 GHz
• 4.3 Gbps
• 2.4 GHz
• 688 Mbps

MIMO

• 6 GHz
• 2 x 2 (DL/UL MU-MIMO)
• 5 GHz
• 2 x 2 (DL/UL MU-MIMO)
• 2.4 GHz
• 2 x 2 (DL/UL MU-MIMO)

Antenna Gain

• 6 GHz
• 6 dBi
• 5 GHz
• 7 dBi
• 2.4 GHz
• 5 dBi

Max. TX Power

• 6 GHz
• 24 dBm
• 5 GHz
• 26 dBm
• 2.4 GHz
• 23 dBm

Wireless Security – WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)

Max. BSSIDs – 4 per Radio

Supported Data Rates

• 802.11a
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b
• 1, 2, 5.5, 11 Mbps
• 802.11g
• 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n
• 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
• 802.11ac (WiFi 5)
• 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
• 802.11ax (WiFi 6/6E)
• 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160)
• 802.11be (WiFi 7)
• 7.3 Mbps to 5.7 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320)

Hardware

• NVR Storage
• Pre-installed 64GB microSD for NVR
• Expansion Slot
• MicroSD Card
• PoE Budget
• 15.4W
• Max. PoE Wattage per Port by PSE
• PoE
• 15.4W
• Voltage Range PoE Mode
• 44-57V
• Max. Power Consumption
• 26W (Excluding PoE output)
• Power Method
• Universal AC input, 100—240VAC, 1.5A Max, 50/60 Hz
• Power Supply
• AC/DC, Internal, 50W
• Supported Voltage Range
• 100—240V AC
• Processor
• Quad-core ARM® Cortex®-A53 at 1.5 GHz
• System Memory
• 3 GB
• Weight
• 1.1 kg (2.4 lb)

Enclosure Material

• Polycarbonate
• LCM Display
• 0.96″ status display
• Management
• Ethernet Bluetooth
• LEDs
• System✓
• Button
• (1) Factory-reset
• ESD/EMP Protection
• Air: ± 8kV, contact: ± 4kV
• Ambient Operating Temperature
• -10 to 40° C (14 to 104° F)
• Ambient Operating Humidity
• 5 to 95% noncondensing
• Certifications
• CE, FCC, IC
• NDAA Compliant✓

Software

• VLAN
• 802.1Q
• Guest Traffic Isolation✓
• Application Requirements
• UniFi Network
• Version 9.0.108 and later
